marcos_orso posted 4 days ago at 4:59 am
Hi.

We are testing this scada system.
It's really nice.
We have made an application with 20 tags, and we want to have access to it from an external network through the vpn solution, is it possible?
When we try to connect using the get from workstation option and setting the ip for vpn we get an unavailable workstation message.

Someone knows how we can connect

regards

1replies
24views
recent by Dave - VTScada  ·  3 days ago at 6:17 pm
Todd posted 3 days ago at 4:18 pm
Any advise on address tags for a s7-1200 example
Tank level located at DB45.4 its a real (float) address and a Boolean address of say DB45.DBX1.4 I have tried multiple ways but I keep getting a 256 error saying bad address. Maybe an integer to like DB6.INT46. I read the help file and tried the 3 differnt ways but kept saying wrong 256

1replies
26views
recent by Dave - VTScada  ·  3 days ago at 5:50 pm
Karstein_Kvistad posted Sep 14 at 12:37 pm
Hello.

I have a String Entry connected to a String I/O tag.
The value of the String I/O is now my name. If I click it, it becomes editable.
But I want it to be locked, uneditable and unselectable. I can toggle Enable Output on the String I/O, this prevents editing. But the blinking dash is still there.
I have tried making a opaque square on top of the text, that can
1replies
29views
recent by Michael  ·  Sep 14 at 3:42 pm
Hello.

I want to extract ONLY the Description of the last Active alarm, and put in a tag. This way I can set any font size on the dynamic alarm text.

I have tried making custom XML alarm settings, and I get the data I want.

<?xml version="1.0" encoding="ISO-8859-1"?>
<AlarmList>
<ColumnFormats>
<Format name="SinglePopupCustom">
<Column
1replies
55views
recent by Michael  ·  Sep 13 at 8:17 pm
How is the video support in VTScada, can't find any good info in neither Developers Guide or Programmers guide.

I am using EmbedWebpage.SRC https://pastebin.com/4Pcvebxu


As example, Youtube works OK, but with a lot of lag. The video format that VTScada is able to show, is WebM - I have not been able to play any other formats.

What I'd really like to do, is to implement a browser
1replies
35views
recent by Vic  ·  Sep 10 at 7:39 pm
exxile000 posted Jul 16 at 10:09 pm
I have a large mobile treatment facility that has not been operated in 4 or 5 years. I just recently refurbished the entire set up and went to launch the scada computer only to find out it is completely shot. I have an old back up of the scada folder but it does not tell me what SCADA program was used to develop. I am hoping that I can utilize VT Scada to import the old programming but have no id
5replies
96views
recent by dougs  ·  Sep 7 at 7:41 pm
Isn't there a way to lock objects, and see which object is on which layer, and lock and turn off layers. And a way to know and decide which object to chose.

I am making Widgets with 5-6 icons on top of each other at several places, opacy turned on by digital inputs, and changes affected by alarms and warnings. It is a nightmare to pick the right object.

Even on a normal page, I keep picki
11replies
105views
recent by Dave - VTScada  ·  Sep 6 at 2:06 pm
I have recently downloaded and installed VT SCADA on my desktop. We are about to purchase the full version and I want to do some training and testing at my desk. I have installed in on two other computers and it works fine. But for some reason on my desktop it shows the start splash screen and then just shuts down and closes before it actuals starts the program. The desktop is fairly new and
1replies
28views
recent by dougs  ·  Sep 2 at 1:39 pm
Karstein_Kvistad posted Aug 31 at 9:13 am
I want to use the values from scaling on a tag - in an expression.
<M251_simulator\Modbus_Driver\SensorNivå1\"Scaled Min">] / 20 * 5
or rather something like this:

[*Numeric\"Scaled Min"] / 20 * 5
This is not working. Gives an error.

What am I doing wrong.


2replies
39views
recent by Karstein_Kvistad  ·  Aug 31 at 12:59 pm
Karstein_Kvistad posted Aug 29 at 2:17 pm
Hello.

I think there is some bug related to the Selector Switches. I have spent countless hours on this, and by accident found a way to make it work. Meaning this must be some bug.

If I make more than a couple Selector Switches, the next one appear with no data. Like 40310 below. I have the exact same settings, because I copy the working Switch. I only change the adress.
Scanning
4replies
72views
recent by Dave - VTScada  ·  Aug 30 at 1:15 pm
Karstein_Kvistad posted Aug 11 at 10:15 am
I would like to use a variable that counts the number of active alarms.

GetContainerNumActive
(Alarm Manager module)
Description: Returns the number of active alarms within a hierarchy of
tags.
Returns: Numeric
Usage: Script or steady state.
Function Groups: Alarm Manager
Related to: Accumulate | GetContainerNumUnacked
Format: GetContainerNumUnacked(ContainerObj);
Parameters:
ContainerObj
Req
7replies
82views
recent by dougs  ·  Aug 29 at 3:13 pm
Karstein_Kvistad posted Aug 2 at 12:44 pm
I have made some custom widgets with several settings, digital- and analog tags. I now entered a problem. See the widget below:


I will animate the dash-bar to move up and down according to some analog value, this is no problem. But I want everything outside the dark box to be invisible.
Inserting the widget to a page makes it look like this:
But I want it to look like this:

10replies
134views
recent by dougs  ·  Aug 11 at 1:53 pm
Why can't I use the same expression for controlling opacity on Numeric Values and images.

(Scale(Analog_verdi\LowWarning\Value, 0, 1, 0, 1) || Scale(Analog_verdi\HighWarning\Value, 0, 1, 0, 1)) && !(Scale(Analog_verdi\HighAlarm\Value, 0, 1, 0, 1) || Scale(Analog_verdi\LowAlarm\Value, 0, 1, 0, 1))
I controll the opacity on a Numeric Value and on a Text Value, and it looks like this, an
1replies
44views
recent by dougs  ·  Aug 9 at 12:50 pm
Is there any way to have the Numeric Entry Text box clear the contents of the entry box when the operator places the cursor in the box?

Currently, where ever the cursor is placed within the entry box that is where the cursor lands, so before the decimal ... after the decimal ... and with some operators at the helm they are not recognizing where the cursor lands and they just start typing the
3replies
45views
recent by bignerb  ·  Aug 7 at 9:47 pm
I have an ipad with the newest iOS firmware 10.3.3, all apps are up to date, yet when I log in the VTScada, after filling out username and password, it gives a white blank page.

Have tried different browsers: Safari, Chrome, Firefox but still not have luck.

I also have another ipad and this one is working fine. So network issues are not this case.

Would you please help me out? Thank
3replies
62views
recent by dougs  ·  Aug 1 at 11:39 pm
brandonf posted Jul 31 at 10:32 pm
I was wondering how the multi color widget works with a single digital input. For some reason I can't figure out how it works. I seen in the programmers guide on how to do it with an analog input and triggers but I couldn't find it used with a digital input.

Basically I was just going to take one digital input tag from my Allen bradley plc and use the multi color widget to display when it i
1replies
30views
recent by dougs  ·  Jul 31 at 11:39 pm
